UC-P33GP
LED pixel lighting
Keywords
LED pixel lighting
Classification
Products
Pixel lighting
UC-P33GP
SPECIFICATION OPTICAL PARAMETERS
| LED Brand: | Taiwan series |
| Color: | RGB |
| Light source: | 3x3535 RGB |
| Beam Angle: | ≥100° |
| Source Life: | 50,000H |
ELECTRICAL PARAMETERS
| Working Voltage: | DC 15V |
| Rated Power: | Maximum 0.9W |
CONTROL PARAMETERS
| Control Method: | DMX512/Serial |
| Gray Scale: | 8Bits/12Bits/16Bits |
| Control System: | UC-ALL the lights control system |
STRUCTURAL PARAMETERS
| Shell Material: | Weather resistance, Fire resistance, ABS / PC lens |
| Surface Color: | Light Gray / Black |
| Structure Size: | 40.5x32.5x17mm |
| Total Weight: | 24g |
ENVIRONMENTAL PARAMETERS
| Working Temperature: | -20°C to 50°C |
| Storage Temperature: | -40°C to 70°C |
| Protection Rating: | IP66 |
| Application environment: | Outdoor |
