UC-P33GP

LED pixel lighting
Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Category
Products
Quantity
-
+
Stock:
0
Product Details
Parameters
颜色:
尺寸:



SPECIFICATION OPTICAL PARAMETERS

LED Brand: Taiwan series
Color: RGB
Light source: 3x3535 RGB
Beam Angle: ≥100°
Source Life: 50,000H

ELECTRICAL PARAMETERS

Working Voltage: DC 15V
Rated Power: Maximum 0.9W

CONTROL PARAMETERS

Control Method: DMX512/Serial
Gray Scale: 8Bits/12Bits/16Bits
Control System: UC-ALL the lights control system

STRUCTURAL PARAMETERS

Shell Material: Weather resistance, Fire resistance, ABS / PC lens
Surface Color: Light Gray / Black
Structure Size: 40.5x32.5x17mm
Total Weight: 24g

ENVIRONMENTAL PARAMETERS

Working Temperature: -20°C to 50°C
Storage Temperature: -40°C to 70°C
Protection Rating: IP66
Application environment: Outdoor





Keyword:
LED pixel lighting
